Connect and Configure the Signify System for the First Time

  1. Select Project > Field Networks > [SORIS network] > [Signify Adapter] > [Signify Configuration]
  2. In the Operation tab, fill out the following connection parameters:
    • Signify URL
    • User
    • Password
    • App Key
    • App Secret
      For each field, enter the value and click Set.
  3. In Configuration, click Create.
  1. The configuration data is acquired and the Signify system objects populate the System Browser tree, under the Signify adapter.

NOTE 1: In the imported object list, the floor-level objects may or may not appear depending on a global option in the Signify Adapter (see Configure the Hierarchy Options).

NOTE 2: To connect to an additional Signify system and add it to the Desigo CC configuration, repeat the procedure above, and enter the connection parameters of the additional system.
Do not use the Signify Configuration node again to change the connection parameters of a system (see Modifying the Signify Connection Parameters).
